7
Illustrated Parts List
3000C Force Feed Loader 7-37
Brakes
Item
No.
Part Number Qty. Description Remarks
1 1010634-47 2 Spring
2 1010634-48 2 O-Ring (Optional)
3 1010634-49 2 Piston
4 1010634-50 4 Back-Up Ring
5 981740-176 4 Bolt, Bleeding
6 981740-175 4 Plug
7 1010634-51 4 Plug (Kit)
8 1010634-52 4 Seal Washer
9 1010634-53 6 Spring
10 1010634-54 6 Adjusting Bolt
11 1010634-55 6 Intermediate Brake Disc
12 1010634-56 6 Brake Disc
13 1010634-57 2 Reduction Bushing
14 1010634-58 6 Adjusting Bolt
15 1010634-59 6 Spring
16 1010634-60 2 Intermediate Brake Disc
17 1010634-61 2 Cover
18 1010634-62 4 Seal
19 1010634-63 2 Spacer
20 1010634-64 1 Shim Kit
21 981740-166 4 Washer, Lock
22 981740-167 4 Nut
23 1010634-65 4 Bolt
24 1010634-72 4 Plug (Optional)
25 1010634-67 2 Piston
26 1010634-68 2 Back-Up Ring
27 1010634-69 2 O-Ring
28 1010634-70 4 Cylinder Bolt
29 1010634-71 4 Dowel
To Next Page
