LeeBoy 3000C - Page 151

7
Illustrated Parts List
3000C Force Feed Loader 7-39
Differential
Item
No.
Part Number Qty. Description Remarks
1 1010634-09 4 Bolt
2 1010634-10 2 Plate, Locking
3 981740-106 2 Ring, Nut
4 981740-114 2 Bearing, Taper Roller
5 1010634-11 20 Bolt
6 1010634-12 1 Carrier, Differential
7 1010634-13 15 Bolt
8 1010634-14 1 Spacer
9 981740-11 1 Shaft w/Gear
10 1010634-15 1 Bevel Gear Set
11 981740-105 2 Bearing, Taper Roller
12 1010634-16 1 Spacer
13 1010634-17 1 Seal
14 1010634-89 1 O-Ring
15 1010634-20 1 Shim
16 1010634-21 1 Intermediate Flange
17 1010634-22 12 Stud
18 981740-132 12 Washer, Spring
19 981740-133 12 Nut
20 981740-130 8 Bolt, Cylinder
21 981740-135 8 Washer, Spring
22 981740-129 1 Spacer
23 981740-104 1 Ring, Nut
24 981740-134 1 O-Ring
25 1010634-23 1 No-Spin Differential (Kit)
