7
Illustrated Parts List
3000C Force Feed Loader 7-45
Conveyor Assembly
Item
No.
Part Number Qty. Description Remarks
1 981386 1 Assembly, Conveyor, 3000
2 750140 A/R Roller, Troughing Idler
3 750090 A/R Roller Assembly, Conveyor Return Idler
4 854741 2 J Bracket, Main Conveyor
5 750610 2 Conveyor Lift Cylinder
6 981438 1 Conveyor Stabilizer
7 750090 3 Roller Assembly, Conveyor Return Idler
8 854795 1 Side Plate, Front Right
9 854799SRV 1 Side Plate, Center Right
10 854797SRV 1 Side Plate, Back Right Side
11 854801 1 Side Plate, Back Left Side
12 854798SRV 1 Side Plate, Center Left Side
13 854796SRV 1 Side Plate, Front Left Side
14 1000284 4 Cylinder, Clevis, 1.00 x 2.75
15 870307 4 Cotter, Hairpin
16 100-8-13-16-5F A/R CSHH, 1/2-13 x 1.00, GR5, FT
17 300-8 A/R Washer, Flat 1/2
18 302-8 A/R Washer, Lock 1/2
19 200-8-16-5 A/R Nut, Hex, 1/2-13, GR5
20 854748-A 2 Clamp, 3-Hole, Top Half
21 854748 2 Clamp, Hose, 3-Hole, Complete Set
22 854748-B 2 Clamp, 3-Hole, Bottom Half
REF 750241A A/R Flashing, 25 x 6.0 x 34. Main Not Shown
REF 986603 2 Safety Pin, Conveyor Mount Not Shown
