LeeBoy 3000C - Page 159

7
Illustrated Parts List
3000C Force Feed Loader 7-47
Tail Pulley Group
Item
No.
Part Number Qty. Description Remarks
1 P202014 1 Belt, Loader, Main Conveyor
2 750080 A/R Pin, Conveyor Belt Lacing, 30”
3 750040 2 Bearing, Flange, 4-Bolt, 2.50, Conveyor Tail Pulley
4 750052 2 Bearing Adjust
5 750050 2 Pulley, Loader
6 750032SRV 1 Bushing, Conveyor Tail Pulley
7 750060A 1 Pulley, Tail, Wing, 10.0 x 32.0
8 750061SRV 1 Guard, Tail Pulley
9 W520862 2 Bolt, Conveyor Adjusting
10 200-12-10-5 2 Nut, Hex, 3/4-10, GR5
11 302-10 8 Washer, Lock, 5/8
12 100-10-11-40-5 4 CSHH, 5/8-11 x 2.50, GR5
13 750131 1 Roller Assembly, Conveyor Troughing, 15 Degree
14 750130 2 Roller Assembly, Conveyor Troughing, 30 Degree
15 300-6 7 Washer, Flat, 3/8
16 204-6-16-5 2 Nut, Lock, .Stover, 3/8-16
17 100-10-11-32-5 4 CSHH, 5/8-11 x 2.00, GR5
18 100-6-16-20-5F 4 CSHH, 3/8-16 x 1.25, GR5, FT
19 302-6 4 Washer, Lock, 3/8
20 986341 9 Roller Assembly (25°), Conveyor Troughing
