Illustrated Parts List
3000C Force Feed Loader 7-49
Head Pulley Assembly
Item
No.
Part Number Qty. Description Remarks
1 P521124 2 Hydraulic Cylinder, Discharge Bafe
2 856997 2 Bar, Round w/2 Holes
3 210060 2 Pin, Clevis
4 710160-28R 1 Bearing, Conveyor Head Pulley Right
5 100-12-10-48-5 2 CSHH, 3/4-10 x 3.75, GR5
6 750321SRV 2 Adjuster Bolt, Main Conveyor Belt Right
7 200-12-10-5 4 Nut, Hex, 3/4-10, GR5
8 750653SRV 1 Frame, Discharge Bafe
9 P521452 12 Elevator Bolt, 1/4-20 x 1.00
10 S521763 1 Strip, Flashing Retainer
11 M521454 1 Rubber Skirt, Discharge Bafe
12 854744 1 Adjuster Rod, Tail Pulley
13 750260 1 Pulley, Head Drum w/Lag
14 750051 2 Bushing, Conveyor Head Pulley
15 750271 1 Shaft, Conveyor Head Pulley
16 750323 1 Snap Ring, Conveyor Left Bearing Retainer
17 520100 1 Bearing, 400 Stub Axle, 3.00
18 854788 1 Motor Mount
19 750300 1 Torque Hub, Conveyor Drive
20 P77494 1 Gasket, C, 4-Hole
21 750310 1 Hydraulic Motor, Main Conveyor Drive
22 100-8-13-40-5 4 CSHH, 1/2-13 x 2.50, GR5
23 300-8 4 Washer, Flat, 1/2
24 302-8 4 Washer, Lock, 1/2
25 100-10-11-32-5 4 CSHH, 5/8-11 x 2.00, GR5
26 300-10 4 Washer, Flat, 5/8
27 302-10 4 Washer, Lock, 5/8
28 100-16-8-32-5F 2 CSHH, 1-8 x 2.00, GR5, FT
29 300-16 2 Washer, Flat, 1
30 302-16 2 Washer, Lock, 1
31 870307 1 Cotter, Hairpin
32 1013205 1 Weldment, Block, Conveyor
