Illustrated Parts List
3000C Force Feed Loader 7-51
Cab Group
Item
No.
Part Number Qty. Description Remarks
1 1000573 1 Group, Cab
For reference only.
Not a replacable part.
2 981439 1 Assembly, Cab Manufactured as one assembly
3 920130 2 Cable, Push/Pull, 123 x 3 Stroke
4 920140 1 Cable, Push/Pull, 116 x 3 Stroke
5 920090 3 Ball Joint, .250, w/.375 Stud
6 151190 1 Blade, Windshield Wiper, 20”
7 151180 1 Arm, Windshield Wiper
8 720260 1 Mirror, Inside Rearview
9 151170 1 Motor, Windshield Wiper
10 760010A-06 1 Plate, Rear Wiper Cover, Front
11 P80676 1 Dome Light, Cab
12 410070 1 Bumper, Water Tank/Conveyor
13 985234 1 Manual Case
14 981512 1 Turn Signal Flasher
REF 151200 1 Tank, Windshield Wiper Washer Not Shown
REF 852810 1 Nozzle Kit, Windshield Washer Not Shown
REF 760010A-02 1 Door Key Not Shown
To Next Page
