Illustrated Parts List
3000C Force Feed Loader 7-61
Instrument Panel
Item
No.
Part Number Qty. Description Remarks
1 1014275 1 Panel, Instrument, Top (Right) Includes 2 - 18
2 1011610-01 1 Plate, Instrument Panel
3 39146-14 1 Switch, Ignition, w/Heat
4 982249 1 Switch, Push Button
5 900030 3 Switch, Toggle, 3-Position
6 851391 3 Switch, Toggle, 2-Position
7 72884 1 Switch, Toggle, 2-Position
8 981505 6 Switch, Toggle, 3-Position
9 1010500 1 Light, Indicator, White
10 853090 2 Switch, Wiper/Washer
11 31985 2 Light, Green, Dash, .50 Hole
12 34964 12 Circuit Breaker, 10A
13 989260 5 Circuit Breaker, 15A
14 1014274 1 Display, DP-250
15 35701 2 Circuit Breaker, 25A
16 989261 1 Circuit Breaker, 30A
17 1011679 1 Decal, Operator, Control Panel, Top
18 1011147 1 Power Outlet, 12-Volt
REF 986546 1 Circuit Breaker, 10A w/Mount Not Shown
19 1011646 1 Panel, Instrument, Bottom (Right) Includes 20 - 33
20 1011646-01 1 Plate, Lower, Instrument Panel
21 851392 1 Switch, Toggle, 3-Position
22 1005965 1 Switch, E-Stop, Base w/Button
23 851391 1 Switch, toggle, 2-Position
24 851393 1 Switch, Toggle, 3-Position
25 72086 1 Switch, Toggle, 2-Position
26 1011680 1 Decal, Operator Control Panel
REF 1010692 1 Contact Block Not Shown
27 151200 1 Tank, Windshield Wiper
28 855148 1 Pressure Check Valve
29 852720 1 Switch, Brake, Low Press
30 720290 1 Solenoid, 12 Volt, Constant Duty
REF 982008-04 1 Key, Iginition Not Shown
31 980990 1 Control, Conveyor/Feeder, Left Side
32 981010 1 Control, Foward/Reverse, Right Side
