Illustrated Parts List
3000C Force Feed Loader 7-69
Muffler and Air Cleaner Arrangement
Item
No.
Part Number Qty. Description Remarks
GRP 1014015 Group, Engine, Loader, T4F
1 1011263-02 1 Air Cleaner, 3000C, T4F
REF 1011263-13 1 Element, Filter, Air, Primary Not Shown
REF 1012474-25 1 Element, Filter, Air, Secondary Not Shown
2 953521244 1 Hump Hose, Reducers, 5.00 - 4.00 ID
3 1000723 1 Pipe, Air Intake, 4.00 x 54.00
4 1011263-04 1 Pre-Cleaner, 3000, T4F
5 1014455 1 Pipe, Exhaust Tip, Loader, T4F
6 1013667-02 1 Aftertreatment, SCR, Vertical
7 1013667-14 1 Aftertreatment, DRT, Cummins, Loader
8 1013667-07 2 Elbow, Stainless Steel, Cummins, Loader
9 1013667-01 1 Aftertreatment, DOC, Loader
10 1013908 1 Weldment, Exhaust, Loader, T4F
11 982779 2 Elbow, Charge, Air, 3.00, 45°
12 1013667-15 2 Elbow, EPDM, 3.00, 45°
13 1011263-06 1 Crankcase, Filter Unit, 3000
14 1013844 1 Pipe, Intake, Turbo Inlet, Loader, T4F
15 161250 2 Clamp, Mufer 3”
16 1012642 2 Hose, Charge Air, Wire Rienforced
17 1000502 1 Tube, Bent, Charge Air, 3.00 OD
18 987282 2 Tube, High Temperature, 3.00 ID, 90°
19 1013847 1 Pipe, Intake, Air Cleaner Outlet, Loader
20 953521243 1 Clamp, T-Bolt, 4.31 - 4.59 Range
21 1000834 1 Elbow, Rubber, 4.00 x 3.00 ID, 90°
22 1013849 1 Pipe, Charge Air, Cooler Inlet, Loader
23 1011617 1 Tube, Upper, Charge Air, T4F
24 171090 5 Clamp, T-Bolt, 3.31 - 3.59 Range
25 1011936 12 Clamp, T-Bolt, Constant Tension
26 1014460 1 Plate, Brace, Intake, Loader, T4F See Figure 7-29
27 1013667-08 4 Clamp, Spherical, Marmon, V-Band, 4.00
28 1013667-09 1 Clamp, Standard, Marmon, V-Band, 3.50
29 1013667-10 1 Clamp, Standard, Marmon, V-Band, 4.00
30 953521243 1 Clamp, T-Bolt, 4.31-4.59 Range
31 39068 1 Clamp, T-Bolt, 5.28-5.59 Range
32 1013667-26 2 Clamp, Exhaust, Accuseal, 5.00
To Next Page
