LeeBoy 3000C - Page 183

7
Illustrated Parts List
3000C Force Feed Loader 7-71
Radiator and Battery Arrangement
Item
No.
Part Number Qty. Description Remarks
GRP 1013667 Engine Cummins, 130HP, T4F
1 1011263-03 1 Radiator, 3000 T4F
2 988748 2 Link, Top Radiator Gusset
3 988759 1 Mount, Radiator (Front)
4 988762 1 Mount, Radiator (Rear)
5 1013667-03 1 Valve, Coolant Control, Cummins
6 1012526-03 1 Tank, DEF, Cummins, 5 Gallon
7 Purchase Locally 2 BAttery, 12V, 835 CCA, Group 24
8 1013935 1 Weldment, Battery Box, Loader, T4F
9 1013937 1 Weldment, Lid, Battery Box, Loader
10 1012641 1 Module, DEF, Supply
11 1014225 1 Hose, Radiator, Lower, Flex, 19.00
12 36395 1 Hose, Radiator, 1.50 x 1.75, 90°
13 1011263-05 1 Fan, Blower, 3000 T4F
14 988986 1 Sensor, Coolant Level
15 1011263-09 1 Tank, Surge, Loader, T4F
16 100-6-16-16-5F 2 CSHH, 3/8-16- x 1.00, GR5, FT
17 302-6 2 Washer, Lock, 3/8
18 300-6 2 Washer, Flat, 3/8
19 100-8-13-28-5 8 CSHH, 1/2-13 x 1.75, GR5
20 302-8 10 Washer, Lock, 1/2
21 300-8 10 Washer, Flat, 1/2
22 200-8-13-5 8 Nut, Hex, 1/2-13, GR5
23 100-8-13-24-8 2 CSHH, 1/2-13 x 1.50, GR8
24 1013667-21 2 Clamp, Hose, Constant-Torque, 1.56 - 2.50 Range
25 1013667-22 2 Clamp, Hose, Constant-Torque, 2.06 - 3.00 Range
26 1013667-25 1 Cap, DEF Tank, Lockable
27 1013924 2 Strap, DEF Tank, Loader
28 100-6-24-16-5F 4 CSHH, 3/8-16 x 1.00, GR5, FT
29 302-6 4 Washer, Lock, 3/8
30 300-6 4 Washer, Flat, 3/8
31 1014338 1 Mount, DEF Supply Module
REF 1014179 1 Cable, Battery, Positive, Loader
REF 1014178 1 Cable, Battery, Negative, Loader
