Illustrated Parts List
3000C Force Feed Loader 7-79
Direction Light Assembly
Item
No.
Part Number Qty. Description Remarks
GRP 1010973 Assembly, Direction Light
1 1010963 1 Subassembly, Weldment, Inner, Direction Light
2 115-#8-12 4 Screw, Self Drilling/Tapping, #8 x 0.75
3 41490 1 Mount, Guidance Lights
4 38139 2 Light, Yellow w/Arrow, 7.00
5 38138 1 Light, Red, 7.00
6 205-#6-32-5 12 Nut, Lock, Nylon, #6-32
7 300-#6 12 Washer, Flat, #6
8 122-#6-32-14F 12 PHMS, Cross, #6-32 x 0.875
9 113-6-16-10 1 Set Screw, Hex Socket Head, Cup, 3/8-16 x 0.625
10 851156 1 Knob, Round Ball, 1.375 x .375-16
11 1010959 1 Subassembly, Weldment, Outer, Direction Light
