7
Illustrated Parts List
3000C Force Feed Loader 7-85
Swivel Conveyor Option
Item
No.
Part Number Qty. Description Remarks
1 1008092 1 Mount, Weldment, Radio/Speaker
2 35136-6 2 Plug, Hole, .750, Flush Mount, Plastic
3 1002021 1 Antenna, AM/FM, Flexible
4 300-4 1 Washer, Flat, SAE, 1/4”
5 302-4 5 Washer, Lock, 1/4”
6 200-4-20-5 1 Nut, Hex, 1/4-20
7 100-4-28-12-5F 4 Capscrew, Hex Head, 1/4-28 x 0.75
8 1011314 1 Radio, AM/FM/CD, w/Auxilary Input & Speakers
9 122-#10-24-12F 8 Panhead Machine Screw, #10-24 x 0.75
10 303-#10 8 Washer, Lock, Extension Tooth, #10
11 300-#10 8 Washer, Flat, #10
12 209-#10-24 8 Nut, Hex, #10-24
12 300-12 4 Washer, Flat, SAE, 3/4
13 1012563 1 Light, LED, Circular
14 P70036 1 Sign, Slow Moving Vehicle
To Next Page
