Illustrated Parts List
3000C Force Feed Loader 7-87
Swivel Conveyor - Hydraulics Option (1 of 2)
Item
No.
Part Number Qty. Description Remarks
1 852740 1 Valve, Brake Charge
2 984876 1 Mount, 2 Speed Valve
3 983361 1 Valve, Trans Shift
4 853850 1 Valve, Solenoid, FWD/REV Shift
5 750602 1 Manifold w/Relief, 3000 Brake
6 1011985 1 Mount, Valve, 2 Sstation, 5 Station
7 160380 1 Valve, Solenoid, Pump Destroke
8 1011461 1 Motor, Hydraulic, 2 Speed, H1-B, 80CC
9 1011461-01 1 O-Rinf Motor Seal
10 858854 1 Manifold, Service Brake, 685
11 853280 1 Manifold, Case Drain
12 853180 1 Switch, Brake Light 3000
13 853310 1 Switch, Pressure, 500 PSI R, N/O
14 1014393 1 Plate, Mount, Test Port, Loader
15 1013583 7 Test Port Hydraulic To #4 JIC Bulkhead
16 1013588-24 2 SMS Test Hose Assembly w/#4 Female JIC Both Ends 24"
17 1013588-72 5 SMS Test Hose Assembly w/#4 Female JIC Both Ends 72"
18 852580 1 Pump, Hydraulic, Gear, Tandem, .58 CIR
19 36808 2 O-Ring, 3.237 ID x .103, SAE 152
20 500140 2 Switch, Vibrator Actuator
21 1010582 1 Hose Kit, 3000, Loader, Manulli
22 985067 2 Hose Wrap, 1/8 x 12 x 12
23 1011869 1 Assembly, Valve, 5 Section W/ Deutsch
24 852750 1 Valve, Solenoid, Swivel Conveyor
25 910158 1 Manifold, Hopper Wing, 1000B
26 550123 2 Manifold, Moldboard Angle Cylinders
27 986557 1 Motor, Hydraulic, Swivel Conveyor Ddrive
28 162803 1 Pump, Hydraulic, Gear, .84 CIR, LH
29 300-6 13 Washer, Flat, SAE, 3/8
30 300-4 18 Washer, Flat, SAE, 1/4
31 300-5 12 Washer, Flat, SAE, 5/16
32 302-6 9 Washer, Lock, 3/8
33 302-4 8 Washer, Lock, 1/4
34 302-5 8 Washer, Lock, 5/16
35 100-6-16-16-5F 8 CSHH, 3/8-16 x 1.00, GR5, FT
To Next Page
