Illustrated Parts List
3000C Force Feed Loader 7-89
Swivel Conveyor - Hydraulics Option (2 of 2)
Item
No.
Part Number Qty. Description Remarks
36 100-4-20-36-5 2 CSHH,1 /4-20 x 2.25, GR5
37 100-4-20-16-5F 2 CSHH, 1/4-20 x 1.00, GR5, FT
38 100-6-16-20-5F 3 CSHH, 3/8-16 x 1.25, GR5, FT
39 100-5-18-16-5F 4 CSHH, 5/16-18 x 1,GR5,FT
40 100-5-18-36-5 2 CSHH,5/16-18 x 2.25, GR5
41 100-4-20-28-5 4 CSHH, 1/4-20 x 1.75, GR5
42 102-4-20-8-F 4 CSSH, 1/4-20 x.50, FT
43 102-5-18-16-F 4 CSSH, 5/16-18 x 1.00, FT
44 204-6-16-5 2 Nut, Lock, Stover, 3/8-16, GR5
45 204-5-18-5 2 Nut, Lock, Stover, 5/16-18, GR5
46 204-4-20-5 4 Nut, Lock, Stover, 1/4-20, GR5
47 217-4-20 2 Nut, Lock, Flexloc, 1/4-20, Full, LT
48 102-M14-2.0-40-8.8F 4 CSSH, M14 x 2.0 x 40,C8.8, FT
49 307-10 4 Washer, Lock, Hi-Collar, 5/8
50 100-M12-1.75-45-8.8F 8 CSHH, M12 x 1.75 x 45, C8.8, FT
REF 993000RS 1 Hose Kit, 3000, Swivel Conveyor Not Shown
