LeeBoy 3000C - Page 203

7
Illustrated Parts List
3000C Force Feed Loader 7-91
Swivel Conveyor Assembly (1 of 2)
Item
No.
Part Number Qty. Description Remarks
GRP 853234 Assembly, Swivel Conveyor
1 853341 1 Assembly, Swivel Mount
2 1000074SRV 1 Swivel Frame
3 853271 2 Pivot Shaft
4 853292 1 Plate, Right Conveyor Side Skirt
5 853293 1 Plate, Left Conveyor Side Skirt
6 853294 2 Plate, Skirt Keeper
7 853342 1 Assembly, Rubber Catch Bracket
8 1004691 1 Head Pulley w/V-Groove, Swivel
9 750090 1 Roller Assembly, Conveyor Idler
10 1004693 1 C-Section, V-Guide Belt, Swivel
11 1000768 1 Tail Pulley Scraper
12 100692 3 Troughing Roller, 2 Roller
13 853248 1 Basket, Swivel Conveyor
14 853339SRV 1 Assembly, Roller Adjuster, Large Drum
15 750622 2 Bracket, Pulley Adjustment
16 750627 3 Mount, Bearing
17 750621 1 Bracket, Pulley Bearing Mount
18 853379 1 Plate, Skirt Keeper
19 853227 2 Bracket, Swivel Conveyer CylinderMount
20 750622-1 1 Adjuster, Conveyor, Head Pully, 12.75Lg
21 750622-2 1 Adjuster, Swivel Conveyor, Tail Pully, 6.75Lg
22 750628 1 Flashing, Front
23 750620 1 Tail Pulley Shaft
24 1004690 1 Tail Pulley, w/V-Groove, Swivel
25 P521124 2 Cylinder, Hydraulic, 2.00 B x 6.00 S x 1.12 R
26 854741 2 J-Bracket/Main Conveyor
