3000C Force Feed Loader
Alphabetical Parts Index
7-117
DESCRIPTION PART # ITEM # FIGURE #
Rubber Skirt, Discharge Bafe M521454 41 7-41
Rubber, Mat, Battery Tray, 3000 T4F 1014504 30 7-34
- S -
Safety Pin, Conveyor Mount 986603 REF 7-19
Scoop Holder Rod Pin 855192 22 7-3
Scoop Level Mounting Plate 855165 34 7-3
Screw, Self Drilling/Tapping, #8 x 0.75 115-#8-12 2 7-36
Seal 210240 16 7-10
Seal 981740-192 2 7-12
Seal 981740-56 48 7-12
Seal 1010634-27 5 7-13
Seal 1010634-29 7 7-13
Seal 1010634-62 18 7-15
Seal 1010634-17 13 7-16
Seal Washer 981740-60 52 7-12
Seal Washer 1010634-52 8 7-15
Seal, 3.628OD x 2.250ID x .468 36830 9 7-10
Seal, Door 760070 7 7-24
Seal, Feeder Shaft 130-342 9 7-5
Seal, Front Window 760090 17 7-24
Seal, Rear Side Window 760090 13 7-24
Seal, Rear Window 760090 15 7-24
Seal, Window 760090 9 7-24
Seat Belt w/Hardware 730-3050 2 7-26
Security Switch 1010634-79 53 7-12
Sender, Temperatire Gauge, 04 MP 35368 23 7-17
Sending Unit, Fuel, Loader 1013942 2 7-18
Sensor, Coolant Level 988986 14 7-32
Set Screw, Hex Socket Head, Cup, 3/8-16 x 0.625 113-6-16-10 9 7-36
Shaft w/Gear 98 1740 -1 1 9 7-16
Shaft, Clip, Conveyor 31800 REF 7-41
Shaft, Conveyor Head Pulley 750271 15 7-21
Shaft, Feeder, Lower 710221A 13 7-5
Shaft, Feeder, Upper 710171A 16 7-6
