Figure 4-3. Machine Dimensions
Table 1-3. Dimension Specications
ITEM SPECIFICATIONS
Length 34’ (10.36 cm)
Overall Height
10’ 5.5” (320 cm) [Minimum]
12’ 11” (393 cm) [Maximum]
Width (Machine) 6’ 11” (212 cm)
Width (Cab) 4’ 4.5” (130 cm)
Weight 19,750 lbs (8,958 kg)
2
Information and Specications
3000C Force Feed Loader
2-5
