Table 1-4.Torque Specications for BSP 30° Inverted
Cone and JIS Coupling Terminations
Table 1-1.Torque Specications for NPTF Dry Seal
Pipe Threads
NPTF
Dash Size Max Torque (ft-lb)
-2 20
-4 25
-6 35
-8 45
-12 55
-16 65
-20 80
-24 95
-32 120
1. The torque values obtained from tightening pipe
threads can vary considerably depending upon
thread condition. Adequate sealing can occur at
values much lower than the maximum values listed
above. Only enough torque to achieve adequate
sealing should be used.
2. When using a male tapered pipe thread with a
female straight or parallel pipe thread, maximum
values are 50% of those listed in the table above.
3. If thread sealant is used, maximum values shown
should be decreased by 25%.
BSP 30° INVERTED CONE AND JIS
Dash Size
Torque (ft-lb)
Min Max
-2 7 9
-4 11 18
-6 19 28
-8 30 36
-10 37 44
-12 50 60
-16 79 95
-20 127 152
-24 167 190
-32 262 314
Information and Specications
3000C Force Feed Loader
2-12
