LeeBoy 5300B - Magnetic Cup Holder

Magnetic Cup Magnetic Cup
HolderHolder
Magnetic cup holders can
be purchased for use with
your machine (and the rest
of your eet). (Figure 4-66)
See your authorized dealer
for details. Ask for Part
Number 1020521.
Figure 4-66. Magnetic
Cup Holder
Tunnel Extension ShieldTunnel Extension Shield
The tunnel extensions attach to the rear of the paver.
(Figure 4-65) This attachment allows material to ow
while paving at wide widths.
Tunnel
Extension
Figure 4-65. Tunnel Extension
To attach the tunnel extension:
1. Loosen the wing bolt on extension.
2. Remove the tube cover.
3. Slide tunnel extension into the tube.
4. Tighten the wing bolt.
44
Operation
LeeBoy Model 5300B Compact Paver 4-51
