GENERAL INFORMATION
The LeeBoy Model 5300B Compact Paver is equipped
with hydrostatic-driven tracks that propel the paver
using friction-controlled joysticks. The two joysticks
control the speed and direction of the paver in
conjunction with the machine speed setting. Ramping
for acceleration and deceleration are proportional to the
movement of the joysticks.
The innovative control panel includes push-button
keypad controls for paving functions. Operators can
choose paving functions at a glance of paving function
symbols on four control panel keypads, which also
illuminates to show function status.
The LeeBoy 5300B Compact Paver offers a unique
feature for paving professionals. The operator can raise
each wing individually. Independent control of one or
both hopper wings allows paving alongside buildings
or other obstructions with ease. When fully open, the
hopper can hold a payload up to seven (7) tons.
Right and left augers rotate to move material from the
conveyors to the screed, and can be operated manually
or in AUTO mode when the optional sonic sensor
system is installed and active.
The screed has hydraulically-controlled extensions that
move in and out to allow a paving base from 4 - 7 feet.
Screed heating is accomplished by electric heating
elements mounted directly to the wear plates for
maximum performance and efciency.
Only authorized personnel who are
properly trained should operate the LeeBoy Model
5300B Compact Paver.
RECEIVING THE MACHINE
Although the machine has been checked thoroughly by
the manufacturer, road hazards or other factors during
transport may result in damage. Be sure to check the
machine thoroughly before operating it:
1. Check engine oil. (Page 5-15)
2. Check hydraulic uid level. (Page 5-20)
3. Check machine hoses for any damage or leaks.
4. Inspect machine for any damage during transport.
Contact your authorized dealer immediately if any
damage has occurred.
Initial and Daily InspectionInitial and Daily Inspection
The following inspection is essential and should be
performed before the initial start-up. Visually inspect the
unit to check its general condition and for familiarization.
Continue with a check of the systems and components
shown in Table 4-1 below:
Table 4-1. Initial Inspection
INSPECT PROCEDURE
Engine Oil
Level
Maintain oil level between ADD and
FULL marks on dipstick.
Fuel Tank
Check for adequate fuel supply. Fill if
needed. Always ll tank at end of the day
to prevent condensation in the tank.
Hydraulic
Tank
Check the tank for oil level and leaks.
Radiator Check coolant level.
Battery
Ensure all cables are tight and clean.
Check for corrosion on the battery
terminals.
Air Cleaner
Check the air lter element and hose
connections. Air cleaner has both a
primary and secondary lter.
Drain Plugs Make sure plugs are inserted and tight.
Engine Belt Check for proper belt tension.
Grease
Fittings
Ensure ttings are greased and in good
working order.
44
Operation
LeeBoy Model 5300B Compact Paver 4-3
