LeeBoy 5300B - Troubleshooting Chart

Troubleshooting ChartTroubleshooting Chart
The troubleshooting chart below identies the most
common symptoms of mechanical problems.
If the problem persists, contact your authorized LeeBoy
dealer for assistance or repair.
SYMPTOM CAUSE REMEDY
Engine does not start.
Defective battery or low battery
charge.
Replace or charge battery as applicable.
Master switch is not set at the
ON position.
Set switch to the ON position.
Insufcient fuel supply. Fill fuel tank.
Safety switch is faulty. Replace.
Solenoid doesn’t function
properly.
Ensure wires are tight.
Clean solenoid plunger.
Replace solenoid coil.
Replace or rebuild starter or solenoid.
Switch box unplugged. Replug switch box.
Neutral switch defective. Replace.
Engine starter relay faulty. Replace.
E-Stop engaged. Disengage E-Stop.
Engine turns over but does
not start.
Low fuel. Add fuel to fuel tank.
Low battery.
Faulty alternator. Replace or rebuild.
Indicator light, bad bulb. Replace.
Machine will not move. RUN/STOP switch faulty. Check RUN/STOP switch.
Machine does not steer
straight.
One of the hydraulic drive
motors needs adjustment.
Readjust motor(s).
Steering control is not centered. Center steering control.
Travel pump defective. Replace or rebuild travel pump.
Machine does not change
speed when the 2-Speed
button is engaged.
Defective relay. Replace relay.
Defective solenoid. Replace solenoid.
Defective drive motor. Replace drive motor.
Maintenance
LeeBoy Model 5300B Compact Paver5-46
