Lower Left KeypadLower Left Keypad
Table 3-3. Control Panel - Lower Left Keypad
KEYPAD
SYMBOL
CONTROL
NAME
FUNCTION
Left Auger AUTO/
MANUAL
Independent right and left augers can be operated in MANUAL or AUTO
(automatic) mode. Manual mode is the default.
• Press button once to turn on the LEFT auger in MANUAL mode. The left
LED light illuminates green.
• Press and hold button 1/2 second to operate in AUTO mode. The right LED
light illuminates green. The auger sonic sensor must be connected to
operate in AUTO mode. (Page 4-39)
• The center blue light illuminates when material reaches the set material
height.
Component Location
LeeBoy Model 5300B Compact Paver3-10
