DETAILED CONTROL PANEL KEYPAD FUNCTIONS
The control panel keypads feature paving symbols that are used for the majority of paver functions. LED lights
illuminate to indicate the function status. Some buttons may only control the side of the machine in which they are
located, or may only function on the active console. The following pages provide detailed information for each
function symbol and status lights.
DM 430 Controller
Joystick
Collar
Ignition
E-Stop
Button
Activate
Control
Panel
Figure 4-1. Starting and Stopping Controls
44
Operation
LeeBoy Model 5300B Compact Paver 4-5
