LeeBoy 5300B - Component Replacement Procedures

Table 2-7. Hydraulic Pressures Specications
ITEM SPECIFICATION
Drive 3,625 psi
Conveyors/Augers 3,050 psi
Cylinders 3,050 psi
Vibrator 3,050 psi
Track Tension Pressure 350 - 400 psi
Track Tension Relieving 2,400 psi
Standby Pressure 400 - 500 psi
Charge Pressure 350 - 400 psi
Table 2-8. Hydraulic System Specications
ITEM SPECIFICATION
Drives Variable volume hydraulic proportional pump
Conveyor/Augers Load sense pump
Cylinder Functions Load sense pump
Hydraulic Oil Reservoir w/Oil Cooler 33 gal
Figure 2-9. Lubricant Specications
ITEM SPECIFICATION
Engine Oil 15W-40, API, CH-4, CI-4
Hydraulic Oil All Weather 32
Torque Hub 90 WT Gear Oil
Grease Shell Avania EP Grease or Equivalent
Chain Lube Chain Lube
Figure 2-10. Spray Down
ITEM SPECIFICATION
Components Electric pump, with one (1) hose and spray wand.
Citrus Wash-down 5 gal
Table 2-6. Hydraulic Filters
ITEM SPECIFICATION
Primary Filter Type Charge Filter
Primary Filter Size 7 Microns
Primary Filter Location Engine Compartment (mounted to hydraulic tank)
Secondary Filter/Strainer Type
Suction Strainers (Stauff TMF-1834-0-0 and TMF-2534-
0-5)
Secondary Filter/Strainer Size
Suction Strainers (125 Micron)
Secondary Filter/Strainer Location
Suction Strainers (inside hydraulic tank)
LeeBoy Model 5300B Compact Paver
2-6
Information and Specications
