002622
F417U2
Operating mode
When in Test mode, by pressing the pushbutton of the actuator it will be possible to enable or disable the associated load.
ON-OFF DIMMING
Manual forcing of the type of load
< 1 s
< 1 s = ON
CAPACITIVE
FORCED
INDUCTIVE
INDUCTIVE
FORCED
CAPACITIVE
10 s = confirm changes
< 1 s = exit without saving changes
< 1 s
< 1 s
SCS Dimmer 2x1.7A
MQ00316-e-EN 09/06/2014
Maintenance
Do not use acetone, detergents for removing tar, or trichloroethylene.
Maintenance using the following products:
- Hexane (En 60669-1);
- Methylated spirit;
- Soap and water;
- Diluted ammonia;
- Bleach, diluted 10%;
- Glass detergents.
WARNING:
An initial test is required in order to use other special maintenance products.
