SCS Dimmer 2x1.7A
MQ00316-e-EN 09/06/2014
NOTE 1): In the Master and Master PUL mode you can set an OFF delay of 0-255 seconds (via
MYHOME_Suite) and of 1-4 minutes using the physical configuration. In the Master and Master
PUL mode you can set an OFF delay of 0-255 seconds (via MYHOME_Suite) and of 1-4 minutes
using the physical configuration. Only for point-point control. The ON control activates the Master
actuator and the Slave actuator at the same time. The next OFF control deactivates the Master
actuator and keeps the Slave actuator active for the period of time set.
2.2 Mode
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Master Actuator Master M=0
Actuator as Slave. Receives a control sent by a Master actuator
with the same address
Slave M=SLA
Pushbutton (ON monostable) ignores Room and General controls Master PUL M=PUL
OFF delay: Master actuator with OFF control delayed on the
corresponding Slave actuator.
1)
0 - 255 M=1 1 minute
M=2 2 minutes
M=3 3 minutes
M=4 4 minutes
2.1 Addressing
Address type Virtual configuration (MYHOME_Suite) Physical configuration
Point-to-point Room 0-10 A=1-9
Lighting point 0-15 PL1, PL2=1-9
Group 1-255 G1, G2=1-9
To use the "Actuator as a slave with PUL function" and adjust the "Minimum brightness
level at power-on" with values 1-100, use MYHOME_Suite virtual configuration.
If the device is installed in a My Home system it can be configured in two ways:
- PHYSICAL CONFIGURATION, inserting the configurators in position.
-
Configuration via MYHOME_Suite software package, downloadable from
www.homesystems-legrandgroup.com; this mode has the advantage of offering many
more options than the physical configuration.
For a list of the procedures and their meanings, please refer to the instructions in this
sheet and to the "Function Descriptions" help section in the MYHOME_Suite software
package.
When installed in a Lighting Management system, the device can be configured in the
following ways:
- Plug & Go: automatic procedure for pairing devices connected to the inputs and
outputs. The procedure is activated on powering the device. It is only available for Room
Controllers or, in the case of other devices, paired with the Room Controllers.
- Push & Learn: procedure for pairing different connected devices or changing the
assignments defined automatically in the Plug & Go procedure. For more details, please
refer to the specific document.
- Software Configuration: using the Virtual Configurator software; for more details, please
refer to the specific manual.
Configuration
1. Lighting Management System
2. My Home system
To Next Page
