Contact interface
in DIN module
2. Automation control
2.1 Addressing
Address type Virtual configuration (MYHOME_Suite) Physical configuration
Point-to-point Room 0-10 A=1-9
Lighting point 0-15 PL1, PL2=0-9
Room 0-10 A=AMB
Group 1-255 A=GR
General general A=GEN
missing in XLS
2.2 Mode
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Type of contact to terminals N1 and N2 Normally open (N/O) SPE=0
Normally closed (N/C) SPE=7
Bistable control
PL1=PL2 SPE=0 M=
Monostable control
PL1=PL2 SPE=0 M=M
With the virtual configuration, for the room, group and general controls, you can set a
light point address for the return of the load status You can also configure the "Installation
level" and the "Destination level".
3. Device locking/unlocking
3.1 Addressing
Address type Virtual configuration (MYHOME_Suite) Physical configuration
Point-to-point Room 0-10 A=1-9
Lighting point 0-15 PL1, PL2=0-9
Room 0-10 A=AMB
Group 1-255 A=GR
General General A=GEN
3.2 Mode
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Type of contact to terminals N1 and N2 Normally open (N/O) SPE=0
Normally closed (N/C) SPE=7
Disable SPE=1 , M=1
Enable SPE=1, M=2
To configure the "Installation level" and the "Destination level" and use MYHOME_Suite
virtual configuration
