110
F428
MQ00283-c-EN 07/06/2014
Contact interface
in DIN module
(room control) and all the amplifiers in the system (general control).
8. Sound system control
This mode allows you to control the amplifiers and the sources of the Sound System.
8.1 Addressing
You can manage a single amplifier (point-to-point control), some amplifiers
Virtual configuration (MYHOME_Suite) Physical configuration
SPE=8
Addressing type Parameter / setting
Point-to-point Room 0-9 0-9
Sound point 0-9 0-9
Room Room 0-9 A=AMB
PF=0-9
General General A=GEN
8.2 Mode
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Type of contact to terminals N1 and N2 Normally open SPE=7
Normally closed SPE=0
ON/volume + SPE=5 , M=0 on button N1
OFF/volume - SPE=5, M=0 on button N2
Change track SPE=5, M=1 on button N1
Click on source SPE=5, M=1 on button N2
Follow me YES SPE=5, M=0
PL2=0 follow me, PL2=1-4 source
NO
For the “Cyclical ON/OFF” function and to select sources 1-9 use the MYHOME_Suite
virtual configuration
