Contact interface
in DIN module
5. Programmed scenario activation
Virtual configuration (MYHOME_Suite) Physical configuration
Type of contact to terminals N1 and N2 Normally open (N/O) SPE=0
Normally closed (N/C) SPE=7
Button N1 0-31 SPE=0 M=CEN
Button N2 0-31 SPE=0 M=CEN
Virtual configuration (MYHOME_Suite) Physical configuration
Addressing type
Room 0-10 A=1-9
Lighting point 0-15 PL1, PL2=1-9
Enabling buttons for sending a command to the scenario programmer MH200N.
The address of the assigned command in positions A and PL must be unique and match
the scenario to be activated. The control can be connected at any point in the system
(local bus or riser).
5.1 Addressing
5.2 Mode
6. Plus Light Management scenario activation
For the configuration please refer to MY HOME_ Suite
7. Plus programmed scenario activation
To configure the address 1 - 2047 of the scenario and the number of buttons 0 - 31 on
the control device, use MYHOME_Suite virtual configuration
NOTE:
If PL1=PL2 the two buttons connected to the interface activate two different scenarios.
If PL1≠PL2 the two buttons activate the same scenario
