113
F429
1 2 3 4 5 6 7 8
A=
1
A=1
PL=1
A=1
PL=2
A=1
PL=3
A=1
PL=4
A=1
PL=5
A=1
PL=6
A=1
PL=7
A=1
PL=8
2
A=2
PL=1
A=2
PL=2
A=2
PL=3
A=2
PL=4
A=2
PL=5
A=2
PL=6
A=2
PL=7
A=2
PL=8
3
A=3
PL=1
A=3
PL=2
A=3
PL=3
A=3
PL=4
A=3
PL=5
A=3
PL=6
A=3
PL=7
A=3
PL=8
4
A=4
PL=1
A=4
PL=2
A=4
PL=3
A=4
PL=4
A=4
PL=5
A=4
PL=6
A=4
PL=7
A=4
PL=8
5
A=5
PL=1
A=5
PL=2
A=5
PL=3
A=5
PL=4
A=5
PL=5
A=5
PL=6
A=5
PL=7
A=5
PL=8
6
A=6
PL=1
A=6
PL=2
A=6
PL=3
A=6
PL=4
A=6
PL=5
A=6
PL=6
A=6
PL=7
A=6
PL=8
7
A=7
PL=1
A=7
PL=2
A=7
PL=3
A=7
PL=4
A=7
PL=5
A=7
PL=6
A=7
PL=7
A=7
PL=8
8
A=8
PL=1
A=8
PL=2
A=8
PL=3
A=8
PL=4
A=8
PL=5
A=8
PL=6
A=8
PL=7
A=8
PL=8
9
A=9
PL=1
A=9
PL=2
A=9
PL=3
A=9
PL=4
A=9
PL=5
A=9
PL=6
A=9
PL=7
A=9
PL=8
OUTPUT
Note: The PL congurator is not required for the physical conguration, as the value is
set by the output to which the DALI device is connected. All the outputs belong to the
same group connected to G.
Depending on the congurator connected to A, the outputs will take the following address:
NOTE 1): In the Master and Master PUL mode you can set an OFF delay of 0-255 seconds (via
MYHOME_Suite) and of 1-4 minutes using the physical configuration. Only for a point-point type
control. With the OFF control the Master actuator deactivates; the Slave actuator deactivates after
the time set with the configurators has elapsed.
Typical function for use in bathrooms without windows where the ON control activates the light
(Master actuator) and the ventilation fan (Slave actuator) at the same time. The OFF control
switches the light off immediately and leaves the fan working for the time set with configurator 1
to 4 in M of the Master actuator as indicated in the table.
1.2 Mode
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Master Actuator Master M=0
Actuator as Slave. Receives a control sent by a Master actuator
with the same address
Slave M=SLA
Pushbutton (ON monostable) ignores Room and General controls Master PUL M=PUL
OFF delay: Master actuator with OFF control delayed on the
corresponding Slave actuator.
1)
0 - 255 M=1 1 minute
M=2 2 minutes
M=3 3 minutes
M=4 4 minutes
To use the "Actuator as a slave with PUL function", to change the "Minimum level" of
the brightness (1 to 100) for additional options of the “Type of load” (Dali standard) use
MYHOME_Suite virtual configuration.
SCS/DALI
gateway
