127
H4651M2
L4651M2
AM581M2
573987
067242
067553
1.1 Addressing
Address type Virtual configuration (MYHOME_Suite) Physical configuration
Point-to-point Room 0-10 A=1-9
Lighting point 0-15 PL=1-9
Room 0-10 A=AMB, PL=1-9
Group 1-255 A=GR, PL=1-9
General general A=GEN, PL=-
Installation and destination level:
The special control can also be used in systems where there are SCS/SCS interfaces (F422).
By installing the control on the BUS of an interface (installation level), you can control one
or more actuators located on the BUS of another interface (destination level).
Function Virtual configuration (MYHOME_Suite) Physical configuration
Destination level Local bus 1-15 I= 1-9
Riser bus riser I=CEN
Complete system entire system I=0
1.2 Mode
1.2.1 ON/OFF control:
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Cyclic SPE=0, M=0
ON SPE=0, M=ON
OFF SPE=0, M=OFF
Button SPE=0, M=PUL
ON with top button, OFF with bottom button. SPE=0, M=O/I
Timed ON 0.5sec SPE=0, M=8
2sec SPE=1, M=7
30sec SPE=0, M=7
1min SPE=0, M=1
2min SPE=0, M=2
3min SPE=0, M=3
4min SPE=0, M=4
5min SPE=0, M=5
10min SPE=1, M=8
15min SPE=0, M=6
Function selection
1. Light switch
Special control
MQ00285-c-EN 09/06/2014
For custom timed ON with period 0 to 255 hours use MYHOME_Suite virtual configu-
ration.
To configure the installation level use MYHOME_Suite virtual configuration.
