1.2.2 ON/OFF Control and ADJUSTMENT (Point-to-Point only):
Virtual configuration (MYHOME_Suite) Physical configuration
Parameter / setting
ON/OFF and cyclic ADJUSTMENT
ON/OFF when pressing briefly and adjustment when holding down
SPE=0, M=O
ON with top button, OFF with bottom button and DIMMER when held down SPE=0, M=O/I
ON with adjustment at 10% SPE=3, M=1
ON with adjustment at 20% SPE=3, M=2
ON with adjustment at 30% SPE=3, M=3
ON with adjustment at 40% SPE=3, M=4
ON with adjustment at 50% SPE=3, M=5
ON with adjustment at 60% SPE=3, M=6
ON with adjustment at 70% SPE=3, M=7
ON with adjustment at 80% SPE=3, M=8
ON with adjustment at 90% SPE=3, M=9
1.2.3 ON/OFF Control and ADJUSTMENT (custom Point-to-Point only).
Virtual configuration (MYHOME_Suite) Physical configuration
Parameter / setting
Switch-on
time (s)
Switch-on level 1
to 99%
ON/OFF and cyclic ADJUSTMENT
ON/OFF when pressing briefly and adjustment
when holding down.
Soft-start and soft-stop setting from 0 to 255 seconds
and switch-on level from 0 to 100%.
1
LIV1=0 – 9,
LIV2=0 – 9
1)
SPE=5 M=0
2 SPE=5 M=1
3 SPE=5 M=2
5 SPE=5 M=3
10 SPE=5 M=4
20 SPE=5 M=5
40 SPE=5 M=6
60 SPE=5 M=7
120 SPE=5 M=8
255 SPE=5 M=9
ON with top button, OFF with bottom button
and DIMMER when held down.
Soft-start and soft-stop setting from 0 to 255 seconds,
switch-on level from 0 to 100%
1
LIV1=0 – 9,
LIV2=0 – 9
2)
SPE=9 M=0
2 SPE=9 M=1
3 SPE=9 M=2
5 SPE=9 M=3
10 SPE=9 M=4
20 SPE=9 M=5
40 SPE=9 M=6
60 SPE=9 M=7
120 SPE=9 M=8
255 SPE=9 M=9
Special control
MQ00285-c-EN 09/06/2014
NOTE 1: Selection of fixed adjustment level from 1% to 99% via positions LIV1=0 – 9 and LIV2=0
– 9. The management is cyclic with ON at the selected level and OFF. If LIV1=LIV2=0, the control
allows cyclically switching ON (at the last saved level) and OFF when pressing briefly. In the case of
point-to-point controls the adjustment is made by pressing and holding down.
NOTE 2: selection of fixed adjustment level from 1% to 99% via positions LIV1=0–9 and
LIV2=0–9. The control is ON at the selected level with the top button and OFF with the bottom
button. If LIV1=LIV2=0, the control allows switching ON (at the last saved level) by briefly press-
ing the top button and OFF with the bottom button; only in the case of point-to-point controls
will pressing and holding down enable making the adjustment (upwards with the top button and
downwards with the bottom button) on 100 levels.
