129
H4651M2
L4651M2
AM581M2
573987
067242
067553
1.2.4 Blink command
When an actuator receives a blink command, it implements it by closing and opening
the relay for a time equal to T that can be configured as shown in the table.
Combine it with a command configured OFF to switch it off.
2.2 Mode
Virtual configuration (MYHOME_Suite) Physical configuration
Parameter / setting
Bistable control
SPE=0 M=
Monostable control
SPE=0 M=M
Virtual configuration (MYHOME_Suite) Physical configuration
Parameter / setting
Blink 0.5 s SPE=2, M=0
Blink 1 s SPE=2, M=1
Blink 1.5 s SPE=2, M=2
Blink 2 s SPE=2, M=3
Blink 2.5 s SPE=2, M=4
Blink 3 s SPE=2, M=5
Blink 3.5 s SPE=2, M=6
Blink 4 s SPE=2, M=7
Blink 4.5 s SPE=2, M=8
Blink 5 s SPE=2, M=9
For blinking with a period of from 5.5 to 8 seconds, use MYHOME_Suite virtual configuration
2. Automation control
2.1 Addressing
Address type Virtual configuration (MYHOME_Suite) Physical configuration
Point-to-point Room 0-10 A=1-9
Lighting point 0-15 PL=1-9
Room 0-10 A=AMB, PL=1-9
Group 1-255 A=GR, PL=1-9
General general A=GEN, PL=-
Installation and destination level:
The special control can also be used in systems where there are SCS/SCS interfaces (F422).
By installing the control on the BUS of an interface (installation level), you can control one
or more actuators located on the BUS of another interface (destination level).
Function Virtual configuration (MYHOME_Suite) Physical configuration
Destination level Local bus 1-15 I= 1-9
Riser bus riser I=CEN
Complete system entire system I=0
Special control
MQ00285-c-EN 09/06/2014
To configure the installation level use MYHOME_Suite virtual configuration.
