130
H4651M2
L4651M2
AM581M2
573987
067242
067553
3.2 Mode
Virtual configuration (MYHOME_Suite) Physical configuration
Parameter / setting
Disable (bottom button) SPE=1 , M=1
Enable (bottom button) SPE=1, M=2
Disable (top button) - Enable (bottom button) SPE=1, M=3
Installation and destination level:
The special control can also be used in systems where there are SCS/SCS interfaces
(F422). By installing the control on the BUS of an interface (installation level), you can
control one or more scenario modules located on the BUS of another interface (destina-
tion level).
3. Device locking/unlocking
3.1 Addressing
Address type Virtual configuration (MYHOME_Suite) Physical configuration
Point-to-point Room 0-10 A=1-9
Lighting point 0-15 PL=1-9
Room 0-10 A=AMB, PL=1-9
Group 1-255 A=GR, PL=1-9
General general A=GEN, PL=-
Installation and destination level:
The special control can also be used in systems where there are SCS/SCS interfaces (F422).
By installing the control on the BUS of an interface (installation level), you can control one
or more actuators located on the BUS of another interface (destination level).
Function Virtual configuration (MYHOME_Suite) Physical configuration
Destination level Local bus 1-15 I= 1-9
Riser bus riser I=CEN
Complete system entire system I=0
4. Scenario module control
4.1 Addressing
Function Virtual configuration (MYHOME_Suite) Physical configuration
Room (of the scenario module) 0-10 A=1-9
Light point (of the scenario module) 0-15 PL=1-9
Function Virtual configuration (MYHOME_Suite) Physical configuration
Destination level Local bus 1-15 I= 1-9
Riser bus riser I=CEN
Complete system entire system I=0
Special control
MQ00285-c-EN 09/06/2014
To configure the installation level use MYHOME_Suite virtual configuration.
To configure the installation level use MYHOME_Suite virtual configuration.
