Basic control for 2 independent loads
1.1 Addressing
Address type Virtual configuration (MYHOME_Suite) Physical configuration
Point-to-point Room 0-10 A1, A2=1-9
Lighting point 0-15 PL1, PL2=1-9
Room 0-10 A1, A2=AMB, PL1, PL2=1-9
Group 1-255 A1, A2=GR, PL1, PL2=1-9
General General A1, A2=GEN
Function selection
1. Light switch
1.2 Mode
1.2.1 ON/OFF control:
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Cyclic. M1, M2=0
ON M1, M2=ON
OFF M1, M2=OFF
Button M1, M2=PUL
Timed ON 0.5sec M=8
30sec M=7
1min M=1
2min M=2
3min M=3
4min M=4
5min M=5
For the “ON/OFF with adjustment” function, “Timed ON” with parameter 2sec, 10min,
15min, “Blinking”, “Cyclic with custom point-to-point adjustment”, “ON/OFF with
custom point-to-point adjustment”, “Cyclic with custom adjustment” and “Custom cyclic
dimmer with no adjustment” use virtual configuration via MYHOME_Suite
1.2.2 ON/OFF Control and ADJUSTMENT (Point-to-Point only):
Virtual configuration (MYHOME_Suite) Physical configuration
Parameter / setting
ON/OFF and cyclic ADJUSTMENT.
ON/OFF when pressing briefly and adjustment when holding down.
M1, M2=0
ON with top button, OFF with bottom button and DIMMER when held down M1, M2=0/1
With the virtual configuration, for the room, group or general controls, you can set a
lighting point address for the return of the load status
