143
067554 H4652/3
AM5832/3 L4652/3
Basic control for
3 independent loads
MQ00290-c-EN 01/08/2013
1.1 Addressing
Address type Virtual configuration (MYHOME_Suite) Physical configuration
Point-to-point Room 0-10 A1, A2, A3=1-9
Lighting point 0-15 PL1, PL2, PL3=1-9
Room 0-10 A1, A2, A3=AMB, PL1, PL2, PL3=1-9
Group 1-255 A1, A2, A3=GR, PL1, PL2, PL3=1-9
General General A1, A2, A3=GEN
Function selection
1. Light switch
2. Automation control
2.1 Addressing
Address type Virtual configuration (MYHOME_Suite) Physical configuration
Point-to-point Room 0-10 A1, A2, A3=1-9
Lighting point 0-15 PL1, PL2, PL3=1-9
Room 0-10 A1, A2, A3=AMB, PL1, PL2, PL3=1-9
Group 1-255 A1, A2, A3=GR, PL1, PL2, PL3=1-9
General general A1, A2, A3=GEN
To configure the mode as Cyclic, Timed ON, Cyclic Dimmer, ON/OFF, with adjustment, OFF,
ON and PUL, use MYHOME_Suite virtual configuration. You can also set a reference ad-
dress for the load status for a room or group control.
For the physical configuration, the device consists of three independent controls and on
the back of the device there are three separate A and PL positions, which relate to the
keys on the front of the control. From left to right, the three buttons correspond to control
1 (A1, PL1), control 2 (A2, PL2), and control 3 (A3, PL3). See table at end of sheet.
With the virtual configuration, for the room, group and general controls, you can set a
light point address for the return of the load status
1.2 Mode
1.2.1 ON/OFF control:
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Cyclic. M=0 See table for functions/button covers
1.2.2 ON/OFF Control and ADJUSTMENT (Point-to-Point only):
Virtual configuration (MYHOME_Suite) Physical configuration
Parameter / setting
ON/OFF and cyclic ADJUSTMENT.
ON/OFF when pressing briefly and adjustment when holding down.
See table for functions/button covers
ON with top button, OFF with bottom button and DIMMER when held down See table for functions/button covers
For custom timed ON with period 0 to 255 hours use MYHOME_Suite virtual configu-
ration.
