1.1 Addressing
Address type Virtual configuration (MYHOME_Suite) Physical configuration
Point-to-point Room 0-10 A=1-9
Lighting point 0-15 PL=0-9
Room 0-10 A=AMB
Group 1-255 A=GR
General General A=GEN
With the virtual configuration, for the room, group and general controls, you can set a
light point address for the return of the load status
You can also configure the "Installation level" and the "Destination level".
1. Light switch
Function selection
1.2 Mode
1.2.1 ON/OFF control:
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Cyclic (point-to-point) SPE=0, M=0
ON SPE=0, M=ON
OFF SPE=0, M=OFF
Cyclic SPE=1, M=7
Button SPE=0, M=PUL
Timed ON 0.5sec SPE=0, M=8
2sec SPE=8, M=1
30sec SPE=0, M=7
1min SPE=0, M=1
2min SPE=0, M=2
3min SPE=0, M=3
4min SPE=0, M=4
5min SPE=0, M=5
10min SPE=7, M=2
15min SPE=0, M=6
For the timed ON control with period 0-255 hours, 0-59 minutes and 0-59 seconds use
MYHOME_Suite virtual configuration
Touch control
MQ00065-d-EN 05/06/2014
