148
HD4653M2
HD4653M3
HC4653/2
HC4653/3
HS4653/2
HS4653/3
1.2.2 ON/OFF Control and ADJUSTMENT (Point-to-Point only):
Virtual configuration (MYHOME_Suite) Physical configuration
Parameter / setting
ON/OFF and cyclic ADJUSTMENT.
ON/OFF when pressing briefly and adjustment when holding down.
SPE=0, M=O
ON and point-to-point dimmer SPE=0, M=ON
OFF and point-to-point dimmer SPE=0, M=OFF
ON with adjustment at 10% SPE=3, M=1
ON with adjustment at 20% SPE=3, M=2
ON with adjustment at 30% SPE=3, M=3
ON with adjustment at 40% SPE=3, M=4
ON with adjustment at 50% SPE=3, M=5
ON with adjustment at 60% SPE=3, M=6
ON with adjustment at 70% SPE=3, M=7
ON with adjustment at 80% SPE=3, M=8
ON with adjustment at 90% SPE=3, M=9
For the functions of "Cyclic with custom point-to-point adjustment", "Cyclic with custom
adjustment", "Cyclic dimmer without adjustment", "Custom dimmer ON without adjust
-
ment", "Custom dimmer OFF without adjustment", "ON with custom adjustment", "OFF
with custom adjustment", "ON and dimmer" and "OFF and dimmer" use MYHOME_Suite
virtual configuration
1.2.3 Blink command
When an actuator receives a blink command, it implements it by closing and opening
the relay for a time equal to T that can be configured as shown in the table.
Virtual configuration (MYHOME_Suite) Physical configuration
Parameter / setting
Blink 0.5 s SPE=2, M=0
Blink 1 s SPE=2, M=1
Blink 1.5 s SPE=2, M=2
Blink 2 s SPE=2, M=3
Blink 2.5 s SPE=2, M=4
Blink 3 s SPE=2, M=5
Blink 3.5 s SPE=2, M=6
Blink 4s SPE=2, M=7
Blink 4.5 s SPE=2, M=8
Blink 5 s SPE=2, M=9
For blinking with a period of from 5.5 to 8 seconds, use MYHOME_Suite virtual config-
uration
2. Automation control
To configure use MYHOME_Suite virtual configuration.
The possible single functions are:
- UP bistable control
- DOWN bistable control
- UP monostable control
- DOWN monostable control
3. Device locking/unlocking
To configure use MYHOME_Suite virtual configuration.
Touch control
MQ00065-d-EN 05/06/2014
