4. Scenario module control
4.1 Addressing
Function Virtual configuration (MYHOME_Suite) Physical configuration
Room (of the scenario module) 0-10 A=1-9
Lighting point (of the scenario module) 0-15 PL=0-9
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Scenario modification and activation 1-16 SPE=6
1)
, M,M2=1-16
4.2 Mode
To configure the "Installation level" and the "Destination level" and f or Button activation
delays use MYHOME_Suite virtual configuration
NOTE 1): By setting configurator 6 in position SPE, the touch control allows you to recall, program
and delete any one of the 16 scenarios contained in a Scenario Module F420.
5. Programmed scenario activation
Virtual configuration (MYHOME_Suite) Physical configuration
Addressing type Room 0-10 1-9
Lighting point 0-15 1-9
Enabling the device for sending a command to the scenario programmer MH200N.
The address of the assigned command in positions A and PL must be different to the
addresses assigned to the actuators. The control can be connected at any point in the
system (local bus or riser).
5.1 Addressing
Programming a scenario
1) Programming the Scenario Module requires enabling programming;
2) Move your hand toward the area of the control sensors (the LEDs will come on at full
brightness) and hold your hand in place, after 3 seconds the LEDs will lower their
brightness level; now move your hand away from the control;
3) The LEDs will start ashing at a very low frequency, indicating activation of the
programming mode;
4) Set the scenario using the controls and/or the corresponding actuators;
5) Briey move your hand toward the control to exit programming mode, the LEDs will
stop blinking and return to the lower brightness level.
Deleting a scenario
1) The Scenario Module must be enabled for programming;
2) Move your hand toward the area of the control sensors (the LEDs will come on at full
brightness) and hold your hand in place, after 3 seconds the LEDs will lower their
brightness level; keep you hand in position for approximately another 5 seconds;
3) The LEDs will start ashing at a high frequency, indicating deletion of the scenario,
and will then return to the lower brightness level.
NOTE: To delete all the scenarios of the Scenario Module use the reset button directly on
the Scenario Module.
Touch control
MQ00065-d-EN 05/06/2014
M
M2 Scenario number
0
1 1
0 2 2
... ... ...
1 6 16
The scenario number can be selected using the congurators 1 - 9 in positions M and M2,
as in the following table. In positions A and PL you need to indicate the address of the
Scenario Module to be controlled.
