150
HD4653M2
HD4653M3
HC4653/2
HC4653/3
HS4653/2
HS4653/3
Virtual configuration (MYHOME_Suite) Physical configuration
Button 0-31 SPE=0 M=CEN Button No.1
5.3 Mode
6. Plus Light Management scenario activation
See MYHOME_Suite virtual configuration
7. Plus programmed scenario activation
To configure the number 1 - 2047 of the scenario and of the buttons 0 - 31 on the
control device, use MYHOME_Suite virtual configuration
To configure in "only press/release" and "press/hold/release" mode use MYHOME_Suite
virtual configuration
8. Video door entry functions
Touch control
MQ00065-d-EN 05/06/2014
8.1 Unlocking control
8.1.1 Addressing
Virtual configuration (MYHOME_Suite) Physical configuration
Same command level SPE=9 M=1
To configure the "External unit address" and the "Riser", "Building" and "Backbone" levels
use MYHOME_Suite virtual configuration
Note 1): Define the address (two digits) of the external unit whose lock is to be controlled.
Addressing type Virtual configuration (MYHOME_Suite) Physical configuration
Address of the external unit 0-95 A=1-9 PL=1-9
1)
Destination level
To set the Riser or Backbone destination level use MYHOME_Suite virtual configuration
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Address of the internal unit from which the lights are controlled. 0-99 SPE=9 M=3
A=1-9, PL=1-9
8.2 Control for stair lighting
8.2.1 Addressing
The device takes on the function of the stair lights power button of the internal unit identified by its address A and PL (two digits).
