151
HD4653M2
HD4653M3
HC4653/2
HC4653/3
HS4653/2
HS4653/3
Touch control
MQ00065-d-EN 05/06/2014
Type of call:
Virtual configuration (MYHOME_Suite) Physical configuration
Function
Point-to-point SPE=9 M=2
8.3 Floor call control
8.3.1 Addressing
Define the address (two digits) of the internal unit to call by using the control device.
Addressing type Virtual configuration (MYHOME_Suite) Physical configuration
Address of the internal unit 0-99 A=1-9 PL=1-9
NOTE: To configure the "General" call use MYHOME_Suite virtual configuration
control) or all the amplifiers in the system (general control).
9. Sound system control
This mode allows you to control the amplifiers and the sources of the Sound System.
9.1 Addressing
You can manage a single amplifier (point-to-point control), some amplifiers (room
Virtual configuration (MYHOME_Suite) Physical configuration
Addressing type Parameter / setting
Point-to-point Room 0-9 A=0-9
Sound point 0-9 PF=0-9
Room Room 0-9 A=AMB
PF=0-9
General General A=GEN
Follow Me mode
Enables, upon powering the amplifier, activating the last source switched on.
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Switch back on from the last source YES YES SPE=8 M=0
NO Definition of the source 1-4 SPE=8 M=1-4
1)
NOTE: For the “ON/volume +”, “OFF/volume -”, Change track”, Click source”, “Cyclic ON/OFF”
function, to switch back on from the last source and to select sources 1-9 use MYHOME_Suite virtual
configuration
NOTE 1): indicates the sound source to be activated before switching on the amplifier.
