154
1) Mode “A” (remote control) M = 1 – 4
This mode allows you to pair the remote control buttons with generic controls (ON/
OFF, UP/DOWN) intended for single or double loads. The correspondence between the
remote control buttons and the controlled loads is determined during installation by the
conguration of positions A and PL1 - PL4 of the IR receiver, as shown in the table below.
The buttons on the remote control can be paired with:
- point-to-point controls, ie for single or double loads (rolling shutter motor) whose
address is specied by the congurator 1 – 9 in positions PL1 – PL4. The dierent
operating modes are determined by pairing the congurators with the respective PL
positions.
- commands intended for actuators for single and double loads, belonging to the
room dened by the congurator 1 – 9 in position A. In this case, the operating
modes are dened by the congurators marked with the graphics of the function
performed, set in positions PL1 – PL4.
Function Type of control Position A Position PL1/PF1 Position PL2/PF2 Position PL3/PF3 Position PL4/PF4
Cyclical ON/OFF when
pressing briey +
adjustment
(dimmer)
lighting point in the room
indicated in A
1 – 9 1 – 9 1 – 9 1 – 9 1 – 9
Cyclical ON/OFF control for
Room 2)
1 – 9 AMB AMB AMB AMB
up-down
rolling shutters
1)
lighting point in the room
indicated in A
1 – 9 1 – 9 1 – 9
1 – 9 1 – 9
1 – 9 1 – 9
1 – 9 1 – 9
1 – 9 1 – 9
1 – 9 1 – 9
up-down rolling
shutters monostable
1)
control for
Room
2)
1 – 9
↑↓ M ↑↓ M
↑↓ M ↑↓ M
↑↓ M ↑↓ M
↑↓ M ↑↓ M
↑↓ M ↑↓ M
↑↓ M ↑↓ M
up-down rolling
shutters until limit
stop
1)
control for
Room
2)
1 – 9
↑↓ ↑↓
↑↓ ↑↓
↑↓ ↑↓
↑↓ ↑↓
↑↓ ↑↓
↑↓ ↑↓
control for ON control for
Room
2)
1 – 9 ON ON ON ON
control for OFF control for
Room
2)
1 – 9 OFF OFF OFF OFF
1) The two PL positions must have the same congurator. The "Up" control is paired
with the rst PL position and the "Down" command with the second PL position.
Example 1: If positions PL2 and PL3 on the receiver have congurator 7, the remote
control operates the double actuator No. 7 of the room indicated in A, raising the rolling
shutters with button 2 and lowering them with button 3.
2) The control is intended for the devices belonging to the room
indicated in A.
Example 2: If positions PL2 and PL3 on the receiver have congurator ↑↓ and position
A has congurator 2, the remote control operates all the actuators in room 2, raising the
rolling shutters with button 2 and lowering them with button 3.
IR Receiver
