In this room it is possible to install up to 4 IR receivers, which enables managing up to
a maximum of 16 separate commands. The correspondence between the channels of a
remote control and the respective IR receiver is established by conguring position M
of the IR receiver.
Congurator in M Remote control channel
1 CH1 to CH4
2 CH5 to CH8
3 CH9 to CH12
4 CH13 to CH16
2) Mode “B” (advanced scenarios) M=CEN
In this mode, the remote control IR 3529 is used as a "scenario control" to activate one
or more advanced scenarios stored in the Scenario Programmer MH200N. The IR receiver
must also be congured in positions A and PL with the numeric congurators to dene
the respective address in the system. Pairing one or more buttons on the remote control
(up to 6) with the scenarios created and stored in the Scenario Programmer MH200N is
done when creating the scenario with the MyHOME_Suite software package.
3) Mode “C” (self-learning remote) M=0
This mode allows you to pair a single command with any button on the remote control.
With a single receiver you can pair up to 16 commands with a remote control. Congure
the receiver with address A=0 and PL = 1 – 9 that cannot be used by actuators.
Commands that the receiver can learn:
- Actuator ON/OFF (cyclical ON/OFF operation for briey pressing and adjustment for
holding down)
- Timed ON
- Flashing
- Rolling shutters UP and DOWN (up-down until the limit stop)
- Actuator Lock/Unlock
- Lights auxiliary ON/OFF (cyclical ON/OFF operation)
- Rolling shutters auxiliary UP/DOWN (up-down until the limit stop)
- Video door entry system (lock and stair lights)
- Sound system (managing the amplier to be controlled)
To pair each remote control channel with a dierent command, the procedure is as
follows:
1) Press the programming button on the receiver for 3 seconds: the LED will come on
with a steady light;
2) Within 20 seconds, press the remote control button for the channel you want to
program: the LED will start ashing, indicating activation of the programming
mode;
3) Set the command you want to assign to the remote control button, using the
controls and/or the corresponding actuator: the LED will come on with a steady
light;
4) You can now repeat steps 2 and 3 for all the buttons, including any button that you
have already assigned in case you want to change it;
5) Press the button to exit the programming mode: the LED will go out;
To clear the programming of one of the remote control channels, the procedure is as
follows:
1) Press the programming button for at least 8 seconds: after 3 seconds, the LED will
come on with a steady light; after another 5 seconds it will turn o; release the
button within 4 seconds: the LED will come on steady;
2) Within 20 seconds, press the remote control button for the channel you want to
clear: the LED will start ashing quickly for approximately 4 seconds, conrming
deletion;
3) From this moment onward, the cleared button will no longer activate any command
until it is reprogrammed. To clear the programming of all the remote control
channels at the same time, press the programming button for approximately 12
seconds: after 3 seconds, the LED will come on with a steady light; after another 5
seconds it will go out; after another 4 seconds it will ash quickly for approximately
4 seconds, conrming deletion of all programming.
NOTE: With the switch in the "padlock closed" position, programming and clearing the
IR receiver is disabled.
IR Receiver
MQ00071-d-EN 05/06/2014
