4) Mode "D" (scenario module control) M=6
This mode enables creating, deleting or modifying the scenarios contained in the
scenario module F420 and calling them up using the remote control. The procedure
allows saving up to 16 scenarios, using all 16 channels of the remote control.
In order to program, change or cancel a scenario, it is necessary to enable the
programming mode of the Module item F420 so that the programming status LED is
green (press the lock/unlock button for at least 0.5 seconds) and the switch on the back
of the IR receiver must be in the "padlock open" position. The procedure is as follows:
1) Press the programming button on the receiver for 3 seconds: the LED will come on
with a steady light; release the button;
2) Within 20 seconds, press the remote control button for the scenario you want to
program: the LED will start ashing, indicating activation of the programming
mode;
3) Set the scenario using the controls and/or the corresponding actuators;
4) Press the button to exit the programming mode: the LED will go out;
5) Repeat steps 1 to 4 for all the scenarios you want to program.
To cancel a scenario, the procedure is as follows:
1) Press the programming button on the receiver for 8 seconds: after 3 seconds, the LED
will come on with a steady light; after another 5 seconds it will turn o; release the
button within 4 seconds: the LED will come on steady;
2) Within 20 seconds, press the remote control button for the scenario you want to
cancel; when the scenario module sends conrmation of the cancellation, the LED
will blink quickly for approximately 2 seconds and then go out;
3) Repeat steps 1 and 2 for all the scenarios you want to cancel.
To reset the entire memory you must act directly on the scenario module. If you want to
disable the ability to program or cancel scenarios with the IR receiver, set the switch on
the back in the "padlock closed" position.
NOTE: Congure the device with address A=0 and PL=1 – 9 that cannot be used by
actuators. For example, if the scenario module is congured with A=0 and PL=3, the IR
receiver must be set to A=0; PL=3 and M=6.
5) Mode “E” (sound system) M=9
In the sound system, the IR receiver can manage up to 4 ampliers. The command is
always in “follow me (*)” mode and the functions that can be performed are:
- Button A: pressing briey runs the “On” command, whereas holding it down
adjusts the volume up
- Button B: pressing briey runs the “O” command, whereas holding it down
adjusts the volume down
- Button C: cycles through the saved radio stations or changes CD track
- Button D: cycles through the sources
Buttons A-B-C-D are paired with the remote control buttons as shown in the table:
Button A Button B Button C Button D
PF1 Ch 1 Ch 2 Ch 3 Ch 4
PF2 Ch 5 Ch 6 Ch 7 Ch 8
PF3 Ch 9 Ch 10 Ch 11 Ch 12
PF4 Ch 13 Ch 14 Ch 15 Ch 16
Where:
- PF1 = 0 – 9 address of the 1st amplier to control
- PF2 = 0 – 9 address of the 2nd amplier to control
- PF3 = 0 – 9 address of the 3rd amplier to control
- PF4 = 0 – 9 address of the 4th amplier to control
- A = 1 – 9 destination room of the control
NOTE (*): Follow Me mode allows you to have the same music in another room after
turning o the amplier in the room you previously occupied and switching on the one
in the room where you are now.
