175
067558 H4660M2
LN4660M2AM5860M2
MQ00591-c-EN 09/06/2014
Rolling shutter management control
If the device is installed in a My Home system it can be configured in two ways:
- PHYSICAL CONFIGURATION, inserting the configurators in position.
- Configuration via MYHOME_Suite software package, downloadable from
www.homesystems-legrandgroup.com; this mode has the advantage of offering many
more options than the physical configuration.
For a list of the procedures and their meanings, please refer to the instructions in
this sheet and to the "Function Descriptions" help section in the
MYHOME_Suite software package.
Configuration
1.3 Mode
Virtual configuration (MYHOME_Suite) Physical configuration
Parameter / setting
Bistable control
M=

Monostable control
M= M
Lath control and bistable control
1)
M=1
Bistable control and lath control
2)
M=2
NOTE 1: Bistable mode when pressed for longer than 1.5 s.
NOTE 2:
Lath control when pressed for longer than 1.5 s.
1.1 Addressing
Address type Virtual configuration (MYHOME_Suite) Physical configuration
Point-to-point Room 0-10 A=1-9
Lighting point 0-15 PL=1-9
Room 0-10 A=AMB, PL=1-9
Group 1-255 A=GR, PL=1-9
General General A=GEN
Function Virtual configuration (MYHOME_Suite) Physical configuration
Installation level Local bus 1-15 not configurable
Riser bus riser not configurable
Standard standard not configurable
Destination level Local bus 1-15 I= 1-9
Riser bus riser I=CEN
Complete system entire system I=0
1.2 Definition of the reference actuator for updating the control status
Function Virtual configuration (MYHOME_Suite) Physical configuration
Room 0-10 Ar=1-9
Lighting point 0-15 PLr=1-9
NOTE: Ar and PLr = configure these two positions only when needing to manage several ac-
tuators with a General, Room or Group type control. The Ar and PLr positions correspond to the
address of the reference actuator for control status update.
