Rolling shutter actuator
MQ00592-c-EN 19/06/2014
If the device is installed in a My Home system it can be configured in two ways:
- PHYSICAL CONFIGURATION, inserting the configurators in position.
-
Configuration via MYHOME_Suite software package, downloadable from
www.homesystems-legrandgroup.com; this mode has the advantage of offering many
more options than the physical configuration.
For a list of the procedures and their meanings, please refer to the instructions in this
sheet and to the "Function Descriptions" help section in the MYHOME_Suite software
package.
1.1 Addressing
Address type Virtual configuration (MYHOME_Suite) Physical configuration
Point-to-point Room 0-10 A=1-9
Lighting point 0-15 PL=1-9
Group Group 1 - Group 10: 0-255 G=0-9
Configuration
1.2 Mode
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Master Actuator
1)
Master M=0
Actuator as Slave. Receives a control sent by a Master actuator
with the same address
Slave M=SLA
Pushbutton (ON monostable) the actuator ignores Room and
General controls
Master PUL M=PUL
NOTE: To adjust the "Stop pulse duration" and "Up or down pulse duration" use MYHOME_Suite
virtual configuration.
1.2.2 Control mode via actuator button
Virtual configuration (MYHOME_Suite) Physical configuration
Parameter / setting
Bistable control
1)
M= 
Monostable control
M= M
Lath control and bistable control
2)
M=1
Bistable control and lath control
3)
M=2
NOTE 1: After acquiring the two positions, closed and open shutter, it will be possible to ma-
nage 100 different positions.
NOTE 2:
Bistable mode when pressed for longer than 1.5 s.
NOTE 3:
Lath control when pressed for longer than 1.5 s.
1.2.1 Type of motor
Virtual configuration (MYHOME_Suite) Physical configuration
Type
Parameter / setting
Standard with manual calibration Standard Type=1
Pulse Pulse Type=2
NOTE 1): Operation based on the mode configured in the control device. After acquiring the posi-
tions of the rolling shutter (open and closed), it will be possible to ensure 100 different positions.
To use the "Actuator as a slave with PUL function" and to define the Preset positions, use
MYHOME_Suite virtual configuration.
