179
H4661M2 LN4661M2
AM5861M2067557
Rolling shutter actuator
MQ00592-c-EN 19/06/2014
1.2.3 Selecting the Preset position
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Rolling shutter opening 10%
1
Pre=1
Rolling shutter opening 20%
2
Pre=2
Rolling shutter opening 30%
3
Pre=3
Rolling shutter opening 40%
4
Pre=4
Rolling shutter opening 50%
5
Pre=5
Rolling shutter opening 60%
6
Pre=6
Rolling shutter opening 70%
7
Pre=7
Rolling shutter opening 80%
8
Pre=8
Rolling shutter opening 90%
9
Pre=9
Operating mode for pulse motors with a 3rd limit switch
After inserting the configurators 2 in the Type socket and 9 in the Pre position of the device, when
the STOP pushbutton of the control is pressed while the shutter is still, the shutter will move to
the position of the 3rd limit switch. If there is no Configurator, the "Preset" function is not active.
NOTE: The proper operation of the PRESET function with shutters provided with adjustable louver
blades, can only be guaranteed by using pulse motors.
To set the "Preset P1-P9: 0-100" use MYHOME_Suite virtual configuration.
Mode of operation of the contacts L1 and L2 of the actuator configured TYPE=2 for the management of the 3° end of stroke.
Default operation TYPE=2 PRE=1-8
STOPPED SHUTTERS
Press ON L1 closes for 0.5 s
Press DOWN L2 closes for 0.5 s
Press STOP PRESET control sending
MOVING SHUTTERS
Press ON L1 closes for 0.5 s
Press DOWN L2 closes for 0.5 s
Press STOP L1 + L2 close for 0.5 s
Operation TYPE = 2 PRE = 9
STOPPED SHUTTERS
Press ON L1 closes for 0.5 s
Press DOWN L2 closes for 0.5 s
Press STOP L1 + L2 close for 0.5 s
MOVING SHUTTERS
Press ON L1 closes for 0.5 s
Press DOWN L2 closes for 0.5 s
Press STOP L1 + L2 close for 0.5 s
