1.2 Lighting
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Master Actuator - Cyclical ON/OFF Master
M1=0
ON with top button, OFF with bottom button - M1=0/I
Actuator as Slave. Receives a control sent by a Master actuator
with the same address
Slave
M1=SLA
Pushbutton (ON monostable) ignores Room and General controls Master PUL
OFF Delay = 0
M1=PUL
Master Actuator with OFF control delayed on the corresponding
Slave actuator.
1)
Master PUL
OFF Delay = 1 - 255
M1=1 1 minute
M1=2 2 minutes
M1=3 3 minutes
M1=4 4 minutes
To define the type of load (lamp, solenoid valve, etc.), use MYHOME_Suite virtual con-
figuration.
NOTE 1): Only for point-point control. With the OFF control the Master actuator deactivates; the
Slave actuator deactivates after the time set on the Master actuator has elapsed. Typical function
for use in bathrooms without windows where the ON control activates the light (Master actuator)
and the ventilation fan (Slave actuator) at the same time. The OFF control switches the light off
immediately and leaves the fan working for the time set with configurator 1 to 4 in M of the
Master actuator as indicated in the table.
1.1 Addressing
Address type Virtual configuration (MYHOME_Suite) Physical configuration
Apartment Room 0-10 A1=0-9
Lighting point 0-15 PL1=1-9
Function selection
1. Lighting Actuator Mode (1 load) or shutter automation with local control
Configure A1, M1 and PL1 to define the local actuator address and mode.
To configure the group address (1-10) from 0 to 255, use MYHOME_Suite virtual con-
figuration.
Control/actuator
MQ00411-e-EN 19/06/2014
If the device is installed in a My Home system it can be configured in two ways:
- PHYSICAL CONFIGURATION, inserting the configurators in position.
-
Configuration via MYHOME_Suite software package, downloadable from
www.homesystems-legrandgroup.com; this mode has the advantage of offering many
more options than the physical configuration.
With the virtual conguration, the functions performed by the front buttons are
independent of the functions of the local actuators.
The software lets you congure 4 independent addresses: 2 for the actuators and 2 for
the front controls.
For a list of the procedures and their meanings, please refer to the instructions in this
sheet and to the «Function Descriptions» help section in the MYHOME_Suite software
package.
Configuration
Light management
“actuator” button cover
