185
067556 AM5851M2
H4671M2 LN4671M2
Control/actuator
MQ00411-e-EN 19/06/2014
1.3 Automation
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Rolling shutter UP/DOWN with STOP after 2 minutes. The
actuator ignores the Room and General controls
Master PUL
M1=OFF
Rolling shutter UP/DOWN with STOP after the set time Master, Slave M1=5 1 minute
M1=6 2 minutes
M1=7 5 minutes
M1=8 infinite
UP/DOWN monostable
-
M1= M
UP/DOWN bistable
-
M1=
To use the “Actuator as a slave with PUL function”, the “Load Type” (Actuator, Rolling
Shutter, Curtain, Gate, Rocker) and define the STOP time 1-60 sec., 2-10 min., use MY-
HOME_Suite virtual configuration.
2. Lighting Actuator Mode (2 separate loads) with local controls
In this mode, the actuator manages two separate loads, connected to the contacts C-L1 and
C-L2 of the two relays, locally controlled with both front buttons, right (load connected in
C-L2) and left (load connected in C-L1).
2.1 Addressing
Address type Virtual configuration (MYHOME_Suite) Physical configuration
Apartment Room 0-10 A1, A2=0-9
Lighting point 0-15 PL1, PL2=1-9
To configure the group address (1-10) from 0 to 255, use MYHOME_Suite virtual con-
figuration.
2.2 Lighting
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Master Actuator - Cyclical ON/OFF Master
M2=0
M1=CEN
ON with top button, OFF with bottom button - M2=0/I
M1=CEN
Actuator as Slave. Receives a control sent by a Master actuator
with the same address
Slave
M2=SLA
M1=CEN
Pushbutton (ON monostable) ignores Room and General controls Master PUL
OFF Delay = 0
M2=PUL
M1=CEN
Master Actuator with OFF control delayed on the corresponding
Slave actuator.
1)
Master PUL
OFF Delay = 1 - 255
M2=1 M1=CEN 1 minute
M2=2 M1=CEN 2 minutes
M2=3 M1=CEN 3 minutes
M2=4 M1=CEN 4 minutes
To define the type of load (lamp, solenoid valve, etc.), use MYHOME_Suite virtual con-
figuration.
NOTE 1): Only for point-point control. With the OFF control the Master actuator deactivates; the
Slave actuator deactivates after the time set on the Master actuator has elapsed. Typical function
for use in bathrooms without windows where the ON control activates the light (Master actuator)
and the ventilation fan (Slave actuator) at the same time. The OFF control switches the light off
immediately and leaves the fan working for the time set with configurator 1 to 4 in M of the
Master actuator as indicated in the table.
Copritasto “attuatore”
gestione tapparella
Lights 1
management
“actuator” button
cover
Lights 1 management
“actuator” button cover
