Congurator summary table:
Socket Function Congurator
ZA zone address 0 – 9
ZB1 Zone address - ON/OFF contact management - Open/Close contact management -
circulation pump mode - OFF zone
0 – 9 – OFF
N1 progressive zone number - Open/Close contact management -
circulation pump progressive number
1 – 9
ZB2 Zone address - ON/OFF contact management - Open/Close contact management -
circulation pump mode - OFF zone
0 – 9 – OFF
N2 progressive zone number - Open/Close contact management -
circulation pump progressive number
1 – 9
Example 1
Conguration and connection of the 2-relay actuator, for the control of the solenoid valves (ON/OFF type) in two dierent zones (zone 1 and zone 2). The progressive zone number is 1.
Legend
1. actuator
2. zone 1 solenoid valve
3. zone 2 solenoid valve
4. zone 1 radiator
5. zone 2 radiator
Actuator conguration
ZA ZB1 N1 ZB2 N2 RL1/C1 RL2/C2
0 1 1 2 1 ON/OFF ON/OFF
