LEGRAND 3440 - Page 320

311
MM00779-a-
M
OUT 3
OUT 2
OUT 1
N
L1 L2
F430R8
OUT 5
OUT 4
OUT 3
OUT 2
OUT 1
OUT 5
OUT 4
L
N
230 Vac
F430R88 relay actuator
Wiring diagrams
Example of connection of a 4-tube fan-coil with On/Off valves.
F430R8
